High Fidelity Actuators

Simulation and Control Technologies offers many high fidelity control loading solutions for many different applications.  SCT will customize a solution for any training environment. Each Electro-Load actuator is designed and manufactured to achieve the highest level of fidelity.  Our Model 2145 actuator produces enough torque to simulate any heavy transport aircraft and is dynamic enough to simulate cyclic response in helicopter applications. Look for our new 2500 line of actuators in mid to late 2011.

Need a custom actuator built?  Click here to give us your requirements for a free assessment.


Download Portable Specs Sheet

High Fidelity 2657-220 Actuator


Continuous Force 220 ft/lbs
Peak Force 440 ft/lbs
Speed (No Load) 840 Deg/S
Weight 63 lbs


Download Portable Specs Sheet

High Fidelity 2657-110 Actuator


Continuous Force 110 ft/lbs
Peak Force 220 ft/lbs
Speed (No Load) 1680 Deg/S
Weight 63 lbs

Download Portable Specs Sheet

High Fidelity 2634-XXXX Actuator


Stroke +/- 2.30 Inch
Continuous Force LBS 592 lbs
Peak Force LBS 1184 lbs
Speed (No Load) 16 In/Sec
Continuous Speed 16 Inches per second


Download Portable Specs Sheet

High Fidelity 2334 Actuator


Stroke +/- 2.00 Inch
Continuous Force LBS 225 lbs
Peak Force LBS 450 lbs
Speed (No Load) 16 In/Sec
Continuous Speed 16 Inches per second


Download Portable Specs Sheet

High Fidelity 2145 Actuator


Continuous Torque @ Output Shaft 180 ft-lbs
Continuous Speed @ Output Shaft 1000 deg/sec
Continuous Force @ Actuator Take of Arm
2.0" Stroke(+/-1.0")
1245 lbs
Continuous Force @ Actuator Take of Arm
4.0" Stroke(+/-2.0")
625 lbs
Peak Torque @ Output Shaft 361 ft-lbs
Peak Force @ Actuator Take of Arm
2.0" Stroke (+/- 1.0")
2500 lbs
Peak Force @ Actuator Take of Arm
4.0" Stroke (+/- 2.0")
1250 lbs


Download Portable Specs Sheet

High Fidelity "Legacy Line" 2051 Actuator


Continuous Torque @ Output Shaft 374 ft-lbs
Continuous Speed @ Output Shaft 123 deg/sec
Continuous Force @ Actuator Take of Arm
2.0" Stroke(+/-1.0")
1664 lbs
Continuous Force @ Actuator Take of Arm
4.0" Stroke(+/-2.0")
825 lbs
Peak Torque @ Output Shaft 749 ft-lbs
Peak Force @ Actuator Take of Arm
2.0" Stroke (+/- 1.0")
3328 lbs
Peak Force @ Actuator Take of Arm
4.0" Stroke (+/- 2.0")
1650 lbs


Download Portable Specs Sheet

High Fidelity "Legacy Line" 2050 Actuator


Continuous Torque @ Output Shaft 250 ft-lbs
Continuous Speed @ Output Shaft 140 deg/sec
Continuous Force @ Actuator Take of Arm
2.0" Stroke(+/-1.0")
1108 lbs
Continuous Force @ Actuator Take of Arm
4.0" Stroke(+/-2.0")
549 lbs
Peak Torque @ Output Shaft 499 ft-lbs
Peak Force @ Actuator Take of Arm
2.0" Stroke (+/- 1.0")
2216 lbs
Peak Force @ Actuator Take of Arm
4.0" Stroke (+/- 2.0")
1098 lbs


Download Portable Specs Sheet

High Fidelity "Legacy Line" 2020 Actuator


Continuous Torque @ Output Shaft 60 ft-lbs
Continuous Speed @ Output Shaft 3000 deg/sec
Continuous Force @ Actuator Take of Arm
2.0" Stroke(+/-1.0")
266 lbs
Continuous Force @ Actuator Take of Arm
4.0" Stroke(+/-2.0")
132 lbs
Peak Torque @ Output Shaft 120 ft-lbs
Peak Force @ Actuator Take of Arm
2.0" Stroke (+/- 1.0")
532 lbs
Peak Force @ Actuator Take of Arm
4.0" Stroke (+/- 2.0")
264 lbs
