Mid Fidelity Actuators

Simulation and Control Technologies offers many mid fidelity control loading solutions for many different applications. SCT will customize a solution for any training environment. Each Electro-Load actuator is designed and manufactured to achieve the highest level of fidelity.

Need a custom actuator built? Click here to give us your requirements for a free assessment



Mid Fidelity 2022 Actuator

Continuous Torque @ Output Shaft 151 ft-lbs
Continuous Speed @ Output Shaft 720 deg/sec
Continuous Force @ Actuator Take of Arm
2.0" Stroke(+/-1.0")
585 lbs
Continuous Force @ Actuator Take of Arm
4.0" Stroke(+/-2.0")
310 lbs
Peak Torque @ Output Shaft 302 ft-lbs
Peak Force @ Actuator Take of Arm
2.0" Stroke (+/- 1.0")
1170 lbs
Peak Force @ Actuator Take of Arm
4.0" Stroke (+/- 2.0")
620 lbs


Download Portable Specs Sheet


Mid Fidelity 2045 Actuator

Continuous Torque @ Output Shaft 299 ft-lbs
Continuous Speed @ Output Shaft 720 deg/sec
Continuous Force @ Actuator Take of Arm
2.0" Stroke(+/-1.0")
1791 lbs
Continuous Force @ Actuator Take of Arm
4.0" Stroke(+/-2.0")
895 lbs
Peak Torque @ Output Shaft 597 ft-lbs
Peak Force @ Actuator Take of Arm
2.0" Stroke (+/- 1.0")
3582 lbs
Peak Force @ Actuator Take of Arm
4.0" Stroke (+/- 2.0")
1790 lbs


Download Portable Specs Sheet


Mid Fidelity 2065 Actuator

Continuous Torque @ Output Shaft 500 ft-lbs
Continuous Speed @ Output Shaft 720 deg/sec
Continuous Force @ Actuator Take of Arm
2.0" Stroke(+/-1.0")
2550 lbs
Continuous Force @ Actuator Take of Arm
4.0" Stroke(+/-2.0")
1275 lbs
Peak Torque @ Output Shaft 1000 ft-lbs
Peak Force @ Actuator Take of Arm
2.0" Stroke (+/- 1.0")
5100 lbs
Peak Force @ Actuator Take of Arm
4.0" Stroke (+/- 2.0")
2550 lbs
