Modular Assemblies

Simulation and Control Technologies offers many modular assemblies for many different applications and demanding environments.  SCT will customize a solution for any training environment.

Need a custom actuator built?  Click here to give us your requirements for a free assessment.


Download Portable Specs Sheet

Modular Center Stick

  • Continuous Speed = 20In/sec
  • Continuous Torque = 70 Lbs
  • Max Torque = 140 Lbs





Modular Side Stick

  • Continuous Speed = 20In/sec
  • Continuous Torque = 70 Lbs
  • Max Torque = 140 Lbs





Modular Collective

  • Continuous Speed = 20In/sec
  • Continuous Torque = 70 Lbs
  • Max Torque = 140 Lbs


Download Portable Specs Sheet

Modular Column/Yoke Assembly

Variation 1

  • Continuous Speed = 20In/sec
  • Continuous Torque = 70 Lbs
  • Max Torque = 140 Lbs

Variation 2:

  • Continuous Speed = 10In/sec
  • Continuous Torque = 140 Lbs
  • Max Torque = 280 Lbs


Steering Wheel

  • Continuous Speed = 3000 deg/sec
  • Continuous Torque = 7 Ft-Lbs
  • Max Torque = 14 Ft-Lbs
